一.简介

GPUImage 共 125 个滤镜, 分为四类

1、Color adjustments : 31 filters , 颜色处理相关
2、Image processing : 40 filters , 图像处理相关.
3、Blending modes : 29 filters , 混合模式相关.
4、Visual effects : 25 filters , 视觉效果相关.

GPUImageHueFilter 属于 GPUImage 颜色处理相关，用来处理图片色度, 色调角度，以度为单位，默认为90度，shader 源码如下：

/******************************************************************************************/
//@Author:猿说编程
//@Blog(个人博客地址): www.codersrc.com
//@File:IOS – OpenGL ES 调节图像色度 GPUImageHueFilter
//@Time:2022/04/01 07:30
//@Motto:不积跬步无以至千里，不积小流无以成江海，程序人生的精彩需要坚持不懈地积累！
/******************************************************************************************/


#if TARGET_IPHONE_SIMULATOR || TARGET_OS_IPHONE
NSString *const kGPUImageHueFragmentShaderString = SHADER_STRING
(
 precision highp float;
 varying highp vec2 textureCoordinate;

 uniform sampler2D inputImageTexture;
 uniform mediump float hueAdjust;
 const highp  vec4  kRGBToYPrime = vec4 (0.299, 0.587, 0.114, 0.0);
 const highp  vec4  kRGBToI     = vec4 (0.595716, -0.274453, -0.321263, 0.0);
 const highp  vec4  kRGBToQ     = vec4 (0.211456, -0.522591, 0.31135, 0.0);

 const highp  vec4  kYIQToR   = vec4 (1.0, 0.9563, 0.6210, 0.0);
 const highp  vec4  kYIQToG   = vec4 (1.0, -0.2721, -0.6474, 0.0);
 const highp  vec4  kYIQToB   = vec4 (1.0, -1.1070, 1.7046, 0.0);

 void main ()
 {
     // Sample the input pixel
     highp vec4 color   = texture2D(inputImageTexture, textureCoordinate);

     // Convert to YIQ
     highp float   YPrime  = dot (color, kRGBToYPrime);
     highp float   I      = dot (color, kRGBToI);
     highp float   Q      = dot (color, kRGBToQ);

     // Calculate the hue and chroma
     highp float   hue     = atan (Q, I);
     highp float   chroma  = sqrt (I * I + Q * Q);

     // Make the user's adjustments
     hue += (-hueAdjust); //why negative rotation?

     // Convert back to YIQ
     Q = chroma * sin (hue);
     I = chroma * cos (hue);

     // Convert back to RGB
     highp vec4    yIQ   = vec4 (YPrime, I, Q, 0.0);
     color.r = dot (yIQ, kYIQToR);
     color.g = dot (yIQ, kYIQToG);
     color.b = dot (yIQ, kYIQToB);

     // Save the result
     gl_FragColor = color;
 }
);
#else
NSString *const kGPUImageHueFragmentShaderString = SHADER_STRING
(
 varying vec2 textureCoordinate;

 uniform sampler2D inputImageTexture;
 uniform float hueAdjust;
 const vec4  kRGBToYPrime = vec4 (0.299, 0.587, 0.114, 0.0);
 const vec4  kRGBToI     = vec4 (0.595716, -0.274453, -0.321263, 0.0);
 const vec4  kRGBToQ     = vec4 (0.211456, -0.522591, 0.31135, 0.0);

 const vec4  kYIQToR   = vec4 (1.0, 0.9563, 0.6210, 0.0);
 const vec4  kYIQToG   = vec4 (1.0, -0.2721, -0.6474, 0.0);
 const vec4  kYIQToB   = vec4 (1.0, -1.1070, 1.7046, 0.0);

 void main ()
 {
     // Sample the input pixel
     vec4 color   = texture2D(inputImageTexture, textureCoordinate);

     // Convert to YIQ
     float   YPrime  = dot (color, kRGBToYPrime);
     float   I      = dot (color, kRGBToI);
     float   Q      = dot (color, kRGBToQ);

     // Calculate the hue and chroma
     float   hue     = atan (Q, I);
     float   chroma  = sqrt (I * I + Q * Q);

     // Make the user's adjustments
     hue += (-hueAdjust); //why negative rotation?

     // Convert back to YIQ
     Q = chroma * sin (hue);
     I = chroma * cos (hue);

     // Convert back to RGB
     vec4    yIQ   = vec4 (YPrime, I, Q, 0.0);
     color.r = dot (yIQ, kYIQToR);
     color.g = dot (yIQ, kYIQToG);
     color.b = dot (yIQ, kYIQToB);

     // Save the result
     gl_FragColor = color;
 }
);
#endif
